Host Interface

USB 2.0

Input

Composite/ S-Video/ Audio L/R

Input Video Resolution

720 x 480@60i, 720 x 576@50i

Capture Video format

NTSC/PAL: 80 x 60 (NTSC only), 88 x 72, 128 x 96, 160 x 120, 176 x 144, 240 x 180, 240 x 176, 320 x 240, 352 x 240, 352 x 288, 640 x 240,640 x 288, 640 x 480, 704 x 576 (PAL, SECAM only), 720 x 240, 720 x 288, 720 x 480, 720 x 576 (PAL, SECAM only)

Pixel Format

NTSC: YUY2 (4:2:2), UYVY (4:2:2)

PAL/SECAM: YUY2 (4:2:2), UYVY (4:2:2), Y8

Color Adjustment

Brightness, Contrast, Hue, Saturation, Sharpness

Programming Language

VB, VC, Delphi, C#, VB.NET

Framework

General DLL

Operating Temperature

Temperature: 0°C to 45°C

Humidity: 0 to 80% RHNC

Storage Environment

Temperature: -30°C to +65°C

Humidity: 0 to 90% RHNC

Power Requirement

5V max 2.06A

Dimension (mm)

82(L) x 28.49(W) x 14(H)

CPU

For SD Video Capturing (AVI Format)

Intel® Pentium® 4.3.0G (HT)

AMD Athlon™ 64 3200+

Intel® Pentium® Mobile Processor 2.0G or AMD equivalent

Memory

512 MB RAM or above

VGA

VGA card with support for DirectX9.0c or above

Sound Card

Yes

Supported OS

Win 7/ 8.1/10 (32/64 bits)*
