Box PC - D115WONB-1 (Orin Nano, Fanless)

Overview
Where to Buy

D115WONB-1

Standard Box PC for NVIDIA® Jetson Orin™ Nano Module

  • Applies to NVIDIA® Jetson Orin™ Nano module

  • 2 x M.2. for WIFI and  SSD

  • 2 x GbE RJ-45 (Optional: Ethernet 1 for PoE ; Ethernet 2 can be used with OOB for NC-SI function )

  • 1 x OOB for Power cycling and Cloud serial console (Optional)

  • 1 x 5G daughter board for 4G/5G card functions (Optional)

  • 2 x USB 3.2 & 1 x HDMI output

  • 20-pins expansion header

  • Operating temperature -25°C~60°C

  • Dimension: W: 126mm x L: 96mm x H: 74mm

  • Support Allxon 24/7 Edge AI device remote management with OOB disaster recovery solutions

Overview



AVerMedia's AI Box PC D115WONB-1 equips powerful NVIDIA® Jetson Orin™ Nano module. This efficient system-on-module (SoM) opens new worlds of embedded IoT applications with full analytic capabilities.



D115WONB-1 Box PC is designed for the industry applications with spatial concern and feature a rich assortment of I/O ports for rapid AI-based solution development and seamless deployment as required by demanding business applications.



AVerMedia supports businesses of all sizes and offers customizable BSP services, flexible MoQ, in addition to NVIDIA's JetPackTM SDK.



Stay Ahead with AVerCooler – Achieving 5°C Lower Operation under Others’ Regular Workload for Enhanced NVIDIA Jetson Efficiency, Extended Lifespan, and Superior Performance.

Key Industries



AVerMedia devices are built with flexibility in mind and are designed for the following verticals.

Smart Retail

Gather and deliver the information to streamline decisions and create more value for the customer.

Smart Camera

Smart cities rely on smart camera feeds to gain situational awareness and respond to real-time safety and security threats.

Smart City

Smart cities rely on live camera feeds to benefit from the video analysis to improve city operations fora variety of services.

Specifications

Model

D115WONB-1

Type

Box PC

NVIDIA Jetson SOM

NVIDIA® Jetson Orin Nano module (8GB)

Networking

2x GbE RJ-45

(Optional: Ethernet 1 for PoE* ; Ethernet 2 can be used with OOB for

NC-SI function** )
1xM.2. key E 2230 for wifi

Display Output

1 x HDMI output3840 x 2160 at 30Hz for Orin Nano

Temperature

Operating temperature -25°C~60°C
Storage temperature -40°C ~ 85°C
Relative humidity 40 °C @ 95%, Non-Condensing

MIPI Camera Inputs

2x 4 lane MIPI CSI-2, 22 pin FPC 0.5mm Pitch Connector

USB

1x USB 2.0 type C for recovery
2x USB 3.2 Type-A

Storage

1x M.2. key M 2280 for NVMe (256G SSD installed in box PC)

Expansion Header (Internal)

20 pins: 2x I2C, 2x UART, 4x GPIOs, 1xCAN (EU terminal block)***

10 pins x2: support OOB module (optional, sold separately)

5-pin & 30-pin wafer: Supports 4G/5G card functions via daughter board (optional, sold separately)

Input Power

DC in JACK on board & ATX 4pin
12V/5A, 9V~24V is recommended.

Power Cord

US/JP/EU/UK/TW/AU/CN

Fan Module

Fanless Solution

Buttons

Power and Recovery

RTC Battery

Support RTC battery and Battery Life Monitoring by MCU

PCB/Electronics Mechanical Info

W: 126mm (W) x 96mm (L) x 74mm (H)
Weight: 1kg (TBD)

Certifications

CE, FCC, KC

Package

1x D115WONB-1 (256G SSD installed)
1x Adapter and Power cable

Ordering Information

Model

SKU Number

NVIDIA SOM

SSD

PSE board*

OOB Module**

5G Daughter Board

D115WONB-1

D115WONB-8G-0013

 Orin Nano 8G

 256G

-

4G module

-

*With the optional OOB module, the default configuration uses Ethernet 2 on the D115W for OOB management, rendering the OOB-Ethernet on the OOB module inactive. Alternatively, we offer another option that allows users to manage via the Ethernet on the OOB module, changing the box PC configuration from 2 RJ45 ports to a total of 3 RJ45 ports, including the RJ45 on the OOB module.

Optional Accessories

Optional Accessories

Specs

MIPI Camera

For 22pin MIPI connector:

1.  Raspberry pi imx219 & imx477 (V2)

2.  Manufacturer: APPRO.PHO

■ B-04: IMX179 (8M) MIPI, 1080P (30fps)



* For details, please refer to the "Accessory-PoE Board" webpage.

** For details, please refer to the "Accessory-OOB module" webpage. Ethernet 2 supports NC-SI for enabling Allxon OOB and In-Band functions simultaneously.

***When equipped with the OOB module, 2x UART will be unavailable.

****Please contact your local sales for more information. All specifications are subject to change without prior notice.
